Wastewater Treatment

OC Series - Open Channel UV

Simply performing

As standards for wastewater reuse become stricter, municipalities need effective effluent disinfection treatment systems

Following several treatment stages, municipal effluent undergoes tertiary filtration and disinfection. While disinfection can be carried out using chemicals, its hazardous impact on the environment and the handling risks presents major challenges. That’s why municipalities are opting for chemical-free UV treatment.

Current UV solutions feature numerous lamps which consume energy and are complex to replace. The lack of adequate monitoring and control causes inefficient water treatment.




All
that's
about to
change

Atlantium’s UV Wastewater
Treatment System

With a successful proven record in closed vessels
for wastewater treatment around the world,
our low pressure, high-intensity system features
an optimized design delivering enhanced performance,
based on Atlantium’s years of experience in designing,
providing, and servicing thousands of UV systems.
The design is based on the most powerful validated CFD-I process, the UV system serves different flow rates and water conditions.

channel set HRZ 02 copy 2-2

Atlantium’s UV system is designed with
optimized flow adjustment structure for eliminating escape route
and increasing system’s efficiency, and with
unique sensors
to continuously monitor UVT levels and lamp operational indicators,
which ensure reliable disinfection levels -
without the headache!

UV dose = UVT x flow rate x lamp output

Untitled-2-1

Optimal flow
adjustment structure


Untitled-22-1

Easy access for
lamp replacement


Untitled-23-1

Lamp cleaning mechanism
enables easy maintenance


Untitled-24-1

Lamp ON indicator
_____

Built-in UVT sensors indicate which lamp needs to be replaced
_____

Easy replacement of lamps - without removing the
entire bank



Untitled-25-1

Advanced and powerful LP
high intensity 1000W lamps = optimal performance with fewer lamps and smaller foot print
_____

Power adjusted from 50% to 100% according to ongoing water quality monitoring


icon new-1

Vertical installation expresses in high energy efficiency -
Less UV photons escape
from the water


Untitled-27-1

Water level sensor



atlantium

Atlantium’s field-proven Hydro-Optic™ (HOD) UV solution
takes water safety to new levels, providing municipalities with sustainable and measurable treatment. As world leaders in UV water treatment, we have
a proven track record of providing municipalities with sustainable, long-term, and high-performance systems.
